Touch Pad Digital Multimeter VA90 With IP67 Waterproof


This touch pad digital multimeter complies with IEC 61010-1, CAT Ⅲ 1000V and CAT IV 600V overvoltage standards. See Specifications of the touch pad digital multimeter below.
Touch pad operation.
6000 counts, dual value display.
IP67 waterproof.
CAT III 1000V / CAT IV 600V application.
Auto backlight.
Digital calibration.
2 colour backlight for various operate status indication.
Chargeable battery selection/ MicroUSB charge/ Wireless charge support.(Option)
Wireless communication.(Option)

Send Inquiry


    Product Features:

    • DATA HOLD mode
    • Manual range and Autorange mode
    • Max/Min mode
    • Relative measurement mode
    • Memory mode
    • Review the data
    • Clear the data
    • Data transmission mode
    • RMS measurement
    • Automatic backlight
    • Automatic power off
    • Automatic Lock TouchPad
    • Test lead plug Indication
    • Red Backlight Alarm
    • Ambient temperature measurement
    • PT Temperature measurement
    • 4-20 mA% Measurement
    • Sub-display frequency measurement

    Product Parameters:

    VA90A VA90B VA90C VA90D
    Base Accuracy 0.20%
    AC/DC Voltage 0~1000 V
    Linear Frequency
    Non-contact Voltage
    AC/DC Current μA/mA/10A
    Temperature K Type  -200℃~1000℃
    Resistance 0~60MΩ
    Capacitance 0~60mF
    TTL Frequency/Duty
    Auto Scan AC/DC
    Auto Range
    Counts 6000
    LCD 2 line LCD
    Back Light AUTO AUTO AUTO
    Auto Power
    Low Battery indication
    Hazard Voltage Indication
    Special Function
    Water Proof IP 67
    Auto Lock/Protect
    Invade Voltage Alarm
    USB Chargeable
    Wireless Chargeable
    Communication WIFI WIFI
    IOS/Android supported
    Battery AA X 2 Li-Battery Li-Battery Li-Battery
    Size 190x90x40 mm
    Weight ~500g (including battery)

    Application and After-Sales Service:

    With Functions of Voltage measurement, Current measurement, Resistance measurement, Capacitance measurement ,Diode test,Continuity test, Temperature measurement, Frequency duty cycle measurement and PC Link, this digital multimeter is ideal for use in the fields, workshop, school, hobby and home applications.


    ∞User’s manual One piece
    ∞Test leads One pair
    ∞ “K” type Thermocouple One piece
    ∞Micro-USB cable One piece *only for Model B/C/D
    ∞PC-Link software CD One piece *only for Model D

    General Maintenance:

    Periodically wipe the case with a damp cloth and mild detergent. Do not use abrasives or solvents.
    Dirt or moisture in the terminals can affect readings.
    To clean the terminals:
    Turn the meter off and remove all test leads.
    Shake out any dirt that may be in the terminals.
    Soak a new swab with a cleaning and oiling agent (such as WD-40).
    Work the swab around in each terminal. The oiling agent insulates the terminals from moisture-related contamination.
    To avoid electrical shock or damage to the meter, do not get water inside the case. Remove the test leads and any input signals before opening the case.
